JD-5 JD-30
Jindun
84158300
Availability: | |
---|---|
Quantity: | |
TECHNICAL PARAMETER
Model | Fuel Available | Heat Output (kcal/h) | Heat Efficiency ( ≥ %) | Fuel Consumption | Control Way | Air Volume (CBM/h) | Outlet Temperature of hot air (°C ) | outlet Temperature of chimney (°C ) | Covering area (m2) | Motor power (KW) | **Size(L*W*H) ( mm) | **Weight (KG) |
JD-5 | Oil | 50,000 | 87 | 7 kg/h | Auto | 5000 | 50-80 | 120-190 | 250-300 | 0.55 | 1350*900*1280 | 350 |
Gas | 9.5CBM/H | |||||||||||
Electric | 58kwh | |||||||||||
JD-10 | Oil | 100,000 | 87 | 12.5 kg/h | Auto | 9000 | 50-80 | 120-190 | 500-600 | 0.55*2 | 1600*1000*1400 | 400 |
Gas | 16 CBM/H | |||||||||||
Electric | 116kwh | |||||||||||
JD-20 | Oil | 200,000 | 87 | 22 kg/h | Auto | 18000 | 50-80 | 120-190 | 1000-1200 | 1.1*2 | 2000*1100*1780 | 600 |
Gas | 29 CBM/H | |||||||||||
Electric | 232kwh | |||||||||||
JD-30 | Oil | 300,000 | 87 | 32.5 kg/h | Auto | 26000 | 50-80 | 120-190 | 1500-1800 | 1.1*3 | 2350*1150*1880 | 900 |
Gas | 42 CBM/H | |||||||||||
Electric | 348kwh |
**Size can be customized and the weight will be changeable according to different size.
TECHNICAL PARAMETER
Model | Fuel Available | Heat Output (kcal/h) | Heat Efficiency ( ≥ %) | Fuel Consumption | Control Way | Air Volume (CBM/h) | Outlet Temperature of hot air (°C ) | outlet Temperature of chimney (°C ) | Covering area (m2) | Motor power (KW) | **Size(L*W*H) ( mm) | **Weight (KG) |
JD-5 | Oil | 50,000 | 87 | 7 kg/h | Auto | 5000 | 50-80 | 120-190 | 250-300 | 0.55 | 1350*900*1280 | 350 |
Gas | 9.5CBM/H | |||||||||||
Electric | 58kwh | |||||||||||
JD-10 | Oil | 100,000 | 87 | 12.5 kg/h | Auto | 9000 | 50-80 | 120-190 | 500-600 | 0.55*2 | 1600*1000*1400 | 400 |
Gas | 16 CBM/H | |||||||||||
Electric | 116kwh | |||||||||||
JD-20 | Oil | 200,000 | 87 | 22 kg/h | Auto | 18000 | 50-80 | 120-190 | 1000-1200 | 1.1*2 | 2000*1100*1780 | 600 |
Gas | 29 CBM/H | |||||||||||
Electric | 232kwh | |||||||||||
JD-30 | Oil | 300,000 | 87 | 32.5 kg/h | Auto | 26000 | 50-80 | 120-190 | 1500-1800 | 1.1*3 | 2350*1150*1880 | 900 |
Gas | 42 CBM/H | |||||||||||
Electric | 348kwh |
**Size can be customized and the weight will be changeable according to different size.
Company Information
Shandong JINDUN Energy Conservation & Environmental Protection Equipment Co., Ltd., located in Dongxia industry estate of Qingzhou city, with 20,000m2 area, is a professional manufacturer of temperature control equipment for agriculturial and industrial ventilation, cooling or heating system, such as ventilation cooling box fan, exhaust cone fan, evaporative water cooling pad, air condition generator and boiler.
Since 2005, as the market leader in manufacturer HVAC system hot air exhaust box fan, ventilation cone cooling fan, honeycomb evaporative cooling pad, energy saving electrical Air heater for chicken house greenhouse, air cooler,air condition generator, hot air stoven and hot water boiler, we provide not only high quality goods but also more additional benefits for our clients and partners.
With advanced production equipment, superb manufacturing process, strict management and with good quality product, we have gotten the certificate of ISO9001 and CE
Under our business ideas "Mutual benefit is based on sincerity ", our goods are sold better and better. Now we are exporting more than 100 countries and areas all over the world. Our annual output is more than 20 million US DOLLAR.
Facing the market, our company will rely on a strong unity, forge ahead with determination and a leadership and workforce to meet the challenge, in fierce competition in the market ahead waves.
JINDUN will be your best business partner.
What We Have
l China Leading Producing Technology
l Super High Quality
l Competitive Price
l Big Production Ability
l Fast Delivery
l Ten Years' Export Experience
l Excellent Sale and After-sale Service
l OEM Available
FAQ
1.Are you a factory or a trading company?
JINDUN EQUIPMENT CO., LTD. is a professional Manufacturer of temperature control equipment since 2005.
2.Can I be your agent?
Yes, welcome to deep cooperation. We have big promotion of JINDUN brand in the market now.
For the details please contact with our overseas manager.
3.Is OEM available?
Yes, OEM is available. We have professional designer to help your brand promotion.
4.Are the products tested before shipping?
Yes, all of our products were qualified before delivery. We test every batch every day.
5.What's your quality guarantee?
We will offer client one year quality guarantee time.
6.What's benefit will you bring?
Your client satisfied on the quality.
Your client continued orders.
Your can get good reputation from your market and obtain more orders.
JINDUN Equipment ’ s super high quality products will bring you success business.
Model No. | ISO9001:2008 high quality Temperature control equipment |
Place of Origin | Qingzhou City, Shandong Province, China |
Brand Name | JINDUN Or OEM |
Products range | Exhaust Fan, ventilation cooling Fan, Evaporative cooling pad, Air condition generator, Hot air stoven, Hot water Boiler. |
Certificate | ISO9001; CE;TUV; SGS |
Main Market | Asia, Africa, South America, Middle East, Europe, etc |
Payment term | T/T,L/C |
MOQ | 1 * 20GP |
Delivery Time | 15 days |
